Model:WTJNR
External turning toolholders(WTJNR)
Description
Type |
Stock |
Dimension(mm) |
Applicable Inserts |
Clamping screw |
Shim |
Wrench |
Clamp |
ClampingStud |
||||||
R L |
a |
b |
L |
h |
s |
e |
||||||||
WTJNR/L 1316H16 |
13 |
16 |
100 |
31 |
20 |
20 |
TN口口1604口口 |
WM0525 |
MT 1603 |
S2.5S4 |
WTL 16 |
SZ0515 |
||
WTJNR/L 1616H16 |
16 |
16 |
100 |
31 |
22 |
32 |
||||||||
WTJNR/L 2020K16 |
20 |
20 |
125 |
31 |
25 |
32 |
||||||||
WTJNR/L 2525M16 |
25 |
25 |
150 |
31 |
32 |
32 |
||||||||
WTJNR/L 3232P16 |
32 |
32 |
170 |
31 |
39 |
36 |
||||||||
WTJNR/L 2525M22 |
25 |
25 |
150 |
25 |
32 |
38 |
TN口口2204口口 |
MT 2204 |
S3S4 |
WTL 22 |
SZ0618 |
|||
WTJNR/L 3232P22 |
32 |
32 |
170 |
32 |
39 |
38 |
||||||||
