Model:MTJNR
External turning toolholders(MTJNR)
Description
Type |
Stock |
Dimension(mm) |
Applicable Inserts |
Clamping screw |
Shim |
Wrench |
Clamp |
ClampingStud |
|||||||
R L |
a |
b |
L |
h |
s |
e |
|||||||||
MTJNR/L 1616H16 |
16 |
16 |
100 |
16 |
20 |
28 |
TN口口1604口口 |
WS06 1025 |
MT 1603 |
S2S3 |
MCL 1814 |
MSP513 |
|||
MTJNR/L 2020K16 |
20 |
20 |
125 |
20 |
25 |
32 |
|||||||||
MTJNR/L 2525M16 |
25 |
25 |
150 |
25 |
32 |
32 |
WS061030 |
||||||||
MTJNR/L 3225P16 |
32 |
25 |
170 |
32 |
32 |
32 |
|||||||||
MTJNR/L 3232P16 |
32 |
32 |
170 |
32 |
32 |
32 |
|||||||||
MTJNR/L 2525M22 |
25 |
25 |
150 |
25 |
32 |
36 |
TN口口2204口口 |
MT 2204 |
S3 |
MCL 2114 |
MSP617 |
||||
MTJNR/L 3225P22 |
32 |
25 |
170 |
32 |
32 |
36 |
|||||||||
MTJNR/L 3232P22 |
32 |
32 |
170 |
32 |
38 |
36 |
|||||||||
